• neck type
• GRXMaple neck

• top/back/body
• Poplar body

• fretboard
• Jatoba fretboardWhite dot inlay

• fret
• Medium frets

• number of frets
• 22

• bridge
• T106 bridge

• string space
• 10.5mm

• neck pickup
• Classic Elite (H) neck pickupPassive/Ceramic

• bridge pickup
• Classic Elite (H) bridge pickupPassive/Ceramic

• factory tuning
• 1E,2B,3G,4D,5A,6E

• string gauge
• .009/.011/.016/.024/.032/.042

• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 42mm at NUT
  • b : Width
  • 57mm at 22F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 305mmR

Features

Maple neck

The Maple neck provides stability and bright tonal character.

Infinity R H-H pickups

Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.

T106 tremolo bridge

The T106 tremolo bridge with 6 independent saddles makes precise height and intonation adjustment of each string easy.

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
